Earthing Funnel

Get a Price/Quote

Product Details:

Mounting Type Direct Mount
Shape Funnel
IP Rating IP33
Efficiency 100% Conductivity
Feature Corrosion Resistant, Durable
Surface Finish Hot Dip Galvanized
Operating Temperature -10C to 55C
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Earthing Funnel Product Specifications

Efficiency 100% Conductivity
Color Silver
Application Electrical Earthing Systems
Rated Voltage 220-240 V
Mounting Type Direct Mount
Weight 350 g
Shape Funnel
IP Rating IP33
Phase Single Phase
Size 100mm
Humidity % Up to 90%
Connection Type Bolt Connection
Protection Level Standard
Material Galvanized Iron (GI)
Connector Type GI Bolt
Surface Finish Hot Dip Galvanized
Feature Corrosion Resistant, Durable
No Of Poles Single
Operating Temperature -10C to 55C
Frequency (MHz) 50 Hz
Product Type Earthing Funnel
Dimension (L*W*H) 100mm x 100mm x 120mm

Compatible Earthing Rod Diameter Up to 16 mm
Installation Method Ground Burial
Resistance Value < 1 Ohm
Usage Environment Outdoor
Product Code EF-100GI

Earthing Funnel Trade Information

Main Domestic Market Gujarat

Product Description

Highlighted as a hot-selling solution, the Earthing Funnel EF-100GI is the enviable choice for any professional in need of redoubtable electrical grounding. This invincible product, weighing just 350g, supports a rod diameter of up to 16 mm and ensures a resistance value of less than 1 Ohm. Designed for outdoor conditions, the galvanized iron ensures durability and corrosion resistance. Boasting a standard protection level and 100% conductivity, this single-pole, single-phase funnel is perfect for high-demand electrical earthing systems. Purchase now from Indias leading distributor, manufacturer, supplier, and trader.

Earthing Funnel Application & Installation Method

The Earthing Funnel EF-100GI is designed specifically for ground burial installation, making it ideal for secure and stable electrical earthing. Suited for single-phase applications, it is typically used for electrical earthing systems to channel fault currents safely into the ground. Common application places include residential, commercial, and industrial outdoor environments, where the noteworthy corrosion resistance and durable properties deliver reliable, long-lasting earthing performance.

Export Market, Certifications & Delivery Protocols

The Earthing Funnel EF-100GI is distributed throughout main export markets in Asia, Africa, and the Middle East, testifying to its broad appeal and robust reliability. Products undergo strict quality certifications, ensuring premium standards. With an efficient outlay, competitive rate, and secure packaging, orders are processed promptly with delivery times tailored to customer location, guaranteeing convenience and satisfaction with every shipment.

FAQs of Earthing Funnel:

Q: How is the Earthing Funnel EF-100GI installed in outdoor environments?

A: The Earthing Funnel EF-100GI is installed using a direct ground burial method, ensuring a secure and stable connection for earthing systems. Simply attach it to a compatible earthing rod (up to 16 mm in diameter) using its bolt connection for optimal performance.

Q: What environments are suitable for using this Earthing Funnel?

A: This product is specifically designed for outdoor environments and can withstand humidity up to 90% and temperatures ranging from -10C to 55C. Its corrosion-resistant galvanized iron construction makes it ideal for various challenging conditions.

Q: When should I consider replacing or inspecting my Earthing Funnel?

A: Regular inspection is recommended, particularly after exposure to harsh environmental conditions or after heavy electrical discharges. Due to its durable design, replacement is typically infrequent unless physical damage or severe corrosion is observed.

Q: Where can the Earthing Funnel EF-100GI be used?

A: This model is perfect for use in residential, commercial, and industrial electrical earthing systems, particularly for installations requiring robust and reliable outdoor earthing protection.

Q: What are the main benefits of using this Earthing Funnel in electrical setups?

A: The EF-100GI offers an enviable performance with a resistance value of less than 1 Ohm, 100% conductivity, and high durability. Its invincible corrosion resistance and robust construction ensure the safety and effectiveness of your earthing system.
